Sectional Door

Product information
Technical specifications

The most prominent feature that makes our sectional doors long-lasting, robust and high quality is that we have used products imported from Europe in all equipment that make up the system. The motor-panel combination is of Germany or Italy (optional), while sandwich panels are of Italian origin. Sectional Doors can be designed according to the walls, ceilings and other features of your building and move by sliding horizontally towards the ceiling, leaving the user the largest free space, purifying from dust, maintaining the ambient air, offering safe and open vision, can be produced in dimensions suitable for your building and long are doors that provide long-lasting use.

LETOON Hangar Door

LETOON Sectional Door

LETOON Hangar Door

LETOON Sectional Door

Brochures

Endüstriyel Seksiyonel Kapı

Media Gallery

Panel Specifications

• Sandwich panel produced from Europe specially produced for sectional doors,

• Sandwich Panels 40 mm thick; It is manufactured as 0.5 mm galvanized steel / condensed polyurethane filler / 0.5 mm galvanized steel,

• Finger tightening security is available between sectional door panels,

• Panel heights are in accordance with general specifications and are 500 and 610 mm.

• Sectional door has 20.000 - 30.000 spring opening-closing number (may increase optionally)

• Sectional door wind resistance is 95kg / m2,

• There are sealing wicks between panels, bottom, top and sides of the door,

• Our sectional doors offer easy opening and closing manually when desired,

• All our sectional doors have options with core panel, flat panel, embossed panel,

• Pneumatic safety system, spring breaking safety system and rope breaking safety system are offered as standard in the package.

• There are aluminum reinforced plates that increase the resistance of the door against impact and wind.

Engine Specifications

• Engine system in accordance with CE and TSE norms of Italy or Germany origin (optional),

Motor power 380 V / 50 Hz, 1 Hp = 736 w,

• Control unit microprocessor electronic control,

• Speed 20 -25 cm / s,

• Frequency of work is 30 laps / hour,

• Bearing capacity for 35 m2 spring balanced loads,

• Motor overload protection is available in overloading,

• It offers the possibility of manual use in case of power failure,
